Maung Aluminium, located in Naypyidaw, Myanmar, stands out as a top manufacturer and supplier of high-quality Aluminium 6061 Forgings, celebrated for their remarkable strength, precision, and durability. With a strong dedication to excellence, the company utilizes advanced forging techniques and rigorous quality control to meet a variety of industrial standards. The Aluminium 6061 Forgings from Maung Aluminium are highly regarded for their outstanding machinability, resistance to corrosion, and reliable performance in challenging environments. The company serves multiple sectors, including aerospace, automotive, marine, and construction, ensuring that each product offers exceptional reliability and mechanical integrity for both structural and high-performance uses.
Aluminium 6061 Forgings are mainly made up of aluminium alloyed with magnesium (0.8–1.2%) and silicon (0.4–0.8%), along with small amounts of copper, chromium, and iron. This blend creates a fantastic balance of strength, hardness, and resistance to corrosion. In terms of mechanical properties, the alloy boasts a tensile strength of about 290 MPa, a yield strength of roughly 240 MPa, and an elongation of around 12%. It also shows excellent fatigue resistance and good weldability, making it perfect for components that need both structural integrity and lightweight performance under various mechanical stresses.
Standards : ASTM B247, B247
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
Maung Aluminium based in Naypyidaw, Myanmar is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 6061 Forgings to meet specific project needs. Our team at Maung Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@maungaluminium.com
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96061 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 | AA6061 | 3.3211 |
Aluminium 6061 Forgings find extensive use in industries that demand high strength-to-weight ratios and outstanding corrosion resistance. You’ll commonly see them in aircraft fittings, automotive parts, marine components, bicycle frames, and structural elements in construction. Their superior machinability and weldability make them ideal for precision-engineered parts like valves, couplings, and hydraulic fittings. In the aerospace and defense industries, these forgings are essential for frames, connectors, and brackets where strength and durability are of utmost importance
Our team is ready to assist you. Contact us for any queries or personalized solutions.
